3C-Link 1000BASE-BX-U, single fiber, TX1310nm/RX1550nm, 20KM, LC, WDM

SFP (Mini GBIC) Small Form-Factor Pluggable (SFP)-is a compact optical transceiver used in telecommunications and data networks. It is popular, widespread, manufacturers of active optical components massively supported module. Its more modern construction gradually displaces the older GBIC.

Unlike the GBIC module, SFP has approximately half the size-smaller dimensions allow the active elements to be installed in a density of up to 24 SFP ports per 1U. It is usually fitted with a duplex LC connector (exception is the single-thread Bi-Directional SFP and metallic SFP transceivers).

SFP modules are produced and supplied in many variants according to the type of fiber, transmission protocol, spanned (up to 200km) and wavelengths.

properties:

• TX: 1310nm
• rx: 1550nm
• transfer speed: 1.25 Gbps
• 1310nm DFB Laser and Pin Photodettor for 20km Transmitting
• satisfies SFP MSA ((multi-source agreement) and SFF-8472
• Connector: LC
• Power: +3.3V
• Operating temperature: 0 °-70 ° C
